Products > Power Inverter > Pure Sine Wave Power Inverter > 12V 220V 500W Pure Sine Wave Portable Power Inverter
Product name : 12V 220V 500W Pure Sine Wave Portable Power Inverter
Item : QW-P500
Price : Please contact us
 Enlarge Image                   Back
←[Previous Product]              [Next Product]→


Details:

12V 220V 500W Pure Sine Wave Portable Power Inverter (QW-P500)

Introduction:
QW-P500 is Pure sine wave inverter which converts DC power to AC power for household appliances, solar devices and telecommunication equipments when there is no grid power.
To prevent damages to this inverter, soft start and safe working performance such as short circuit protection are added into its standard design. The cool shell and inner fan also help improve its performance.

Features:
1. Conversion efficiency over 90%
2. Output 50Hz/220Vac pure sine wave suitable for Solar power system, all the home appliances and equipments, such as Mobile phone, Computer,Tablet, PAD, Camera, TV, Shaver, DVD, Fan, Lamp, Game machine, Induction Cooker, Computer, refrigerator, Air conditioner etc.
3. High Stability: Since it has over voltage, under voltage, overload, overheating, short circuit, reverse and improved protection, stability of the system
4. Max 500W Continuous output power
5. Independent research and development design, adopting the latest technology and developments, and have a long operating life
6. Output are pure sine wave same as the mains power, never harm to any load.
7. Adopting the copper transformer, making the inverter working stable and reliable, and with more load capacity. Suitable for solar power system.
7. Multifunction socket suitable for worldwide plug application, such as American, European and Australian standard plug.


Technical Parameter:
500W PURE SINE WAVE POWER INVERTER
Output Output Voltage 100/110/120/220/230/240VAC
Rated Power 500W
Peak Power 1000W
Waveform Pure Sine Wave
Frequency 50Hz/60Hz
Output Voltage error value low & high 10%
no-load loss <7W
Efficiency >90%
Input LED indicator Working status,error status
Input Voltage 10-15VDC
Working Voltage 12VDC
Protections Fuse 35A
Low voltage alarm 10.5+0.3V
Low voltage shut down 10+0.5V
Over voltage shut down 15.5+0.5V
Over load shut down 600W over 10 seconds
Overheat shut down >75ºC
Overheat Output shut off
Working temperature '-10ºC and +50ºC
soft-start
Packing Product Size 218*150*70mm
Inner box size 240*175*95mm
Outer carton size 64*42.5*29cm
Net weight 1.85±0.2KG
Gross weight 16±1KG
Packing Qty 8PCS/CTN


Application:
Wind generation, solar panel, home, office, car, board and some place that lack electricity. Ideally suitable for Journeys, Camping, Tents, Boat Trip, Working on the way and everywhere, where is no electricity!

Load:
1> Office equipment series: Computers, Printers, Copiers, Scanners, digital camera, etc.
2> Household appliances series: Vacuum cleaners, Fans, Lighting, Electric cutting knife, Television, Sewing machines, Electric fans, AC, etc.
3> Kitchen utensils series: Microwave ovens, Freezers, Coffee machines, Blenders, induction cooker, etc.
4> Electronics Series: TV, VCR, Game consoles, Radios, Power amplifiers, Audio equipment, Monitoring equipment, Terminal equipment, Intelligence platforms, Satellite communications equipment.
5> In-car or on-boat devices series: Military vehicle, police cars, medical ambulance, ships, traffic lights, and etc.
6> Industry equipments series: Solar energy, wind power, gas discharge lamp and etc.
                                   User Guide
Application Wattage Inverter Wattage
150W 300W 500W 800W 1000W 2000W 3000W 4000W
Mobile phone 5W
12 inch color television 16W
Video games console 20W
Electric light 25W
Satellite TV receiver 30W
CD or DVD player 30W
HiFi stereo 4-Head VCR 40W
Guitar amplifier (at average volume) 40W
Stereo system (at average volume) 55W *
Electric fan 55W
Notebook 60W
GE 9 inch color TV/radio/cassette 65W
19 inch color TV 80W
20 inch VCR combo 110W
27 inch color TV 170W
Stereo amplifier 250W   * *
Small-medium printer 350W     * * *
Home theater system 400W     * * *
Power drill 400W
Rice cooker 500W
Small coffee machine 600W       * *
Refrigerator 750W       * * *
Small microwave oven 800W       * * *
Toaster 1000W         * *
Hair dryer 1000W
Full size microwave oven 1500W           * * *
Electric kettle 1800W
Induction cooker 2000W           * * *
washing machine 2500W             * *
Air conditioner 16000BTU 2500W               *
Air compressor 3HP 2800W               *
Heavy duty power tools 2800W               *
Air conditioner 22400BTU 3500W               *

Note: For those starred models, pure sine wave inverters are preferred.



Payment Terms:
T/T, Western Union, Money Gram
Production arranged after receipt of payment.

Lead Time:
Sample order will be delivered within 7 working days.
Order quantity below 100PCS, delivery time is 7-15 working days.
Container order will be delivered within 15-30 working days.

Shipment:
Courier: FedEx, DHL, TNT, UPS, Aramex, EMS ect.
Forwarder: By sea / air or Customer designated


FAQ:

1. What is inverter?
Inverter is an electronic equipment that turn 12v/24v/48v dc into 110v/220v ac.

2. What is the difference between the inverter with UPS + charger and inverter with charger?

A2: UPS inverter: When the mains is on, the current through the inverter power to the load, and at the same time charge the battery. When mains drops, it will automatic transfer and let the battery to supply power for the load: Current flow direction is: Battery - inverter - Load.

With battery without UPS inverter: When the mains is on, the main electricly charge the battery, and the current of the battery through the inverter power to the load, always use battery power, without automatic transfer function.


3. What can a UPS do for me?

A1: Every UPS will supply power to a load (such as a computer, telephone switch or medical equipment) when mains power fails, it may also condition the power and prevent spikes, brownouts, interference and other unwanted problems from reaching the supported equipment.
